West Africa | North Africa | East Africa | Southern Africa
Arshya Pipe Fittings supplies buttweld elbows, tees, reducers, caps and stub ends to distributors, EPC contractors and plant owners across Africa. Fittings are manufactured at our group manufacturing facility, which holds ISO, PED (TÜV), AD 2000, IBR and ASME approvals. India is a short sea passage from the ports of East and Southern Africa, and we ship regularly to West and North African ports, so project lists and stockist orders can be planned with reliable transit times.
| Dimensions | ASME B16.9 / B16.28, EN 10253-2 / -4 |
| Carbon & low temp | A234 WPB, A420 WPL6, A860 WPHY 42–70 |
| Chrome moly | A234 WP11, WP22, WP5, WP9, WP91 |
| Stainless & duplex | A403 WP304L, WP316L; A815 duplex, super duplex |
| Size | ½" to 48", Sch 10 to XXS |
| Documents | EN 10204 3.1 std, 3.2 on request |
| Terms | FOB Nhava Sheva, CFR or CIF your port |
Upstream facilities, gas processing, LNG and pipelines in West, North and East Africa: carbon steel, WPL6 for low temperature, WPHY pipeline grades and NACE MR0175 sour-service options. See oil and gas.
Chrome-moly WP11, WP22 and WP5 for heater and hydrotreater lines, stainless for ammonia and urea service.
P11, P22 and P91 fittings for steam piping in gas-fired, combined-cycle and coal plants. See power generation.
Stainless, duplex and nickel-alloy fittings for acid and slurry service in copper, cobalt and other mineral processing plants.
Duplex and super duplex for seawater intake and reverse-osmosis plants. See desalination.
Mixed container loads of standard sizes for local stock. See our distributor programme.
Every order includes EN 10204 3.1 certificates with heat-number traceability, a commercial invoice, packing list and certificate of origin. Bureau Veritas, SGS, DNV or your own inspector can witness testing and sign EN 10204 3.2 certificates.
Several African countries run pre-shipment inspection or product conformity programmes. Tell us your destination at the quotation stage and we will provide the test certificates and commercial documents those programmes ask the exporter for.
We ship by sea from Nhava Sheva (Mumbai) in seaworthy wooden cases or pallets, with bevel ends protected, on FOB, CFR or CIF terms.
Yes. We supply ASME B16.9 and EN 10253 buttweld fittings to distributors, EPC contractors and plant owners across West, North, East and Southern Africa.
EN 10204 3.1 certificates, commercial invoice, packing list and certificate of origin as standard. Tell us your destination country and we will confirm any extra documents its pre-shipment inspection or conformity programme needs from the exporter.
Yes. Bureau Veritas, SGS, DNV or your nominated inspector can witness testing in India and sign EN 10204 3.2 certificates.
Yes, when the order specifies it. We supply to NACE MR0175 / ISO 15156 hardness limits and report hardness on the certificate.
Reply from our Mumbai sales office, usually within one working day. You can attach drawings by email to marketing@arshyafittings.com.
