Mexico | Brazil | Chile | Peru | Colombia | Argentina
Arshya Pipe Fittings supplies buttweld elbows, tees, reducers, caps and stub ends to distributors, EPC contractors, mining companies and plant owners across Latin America. Fittings are manufactured at our group manufacturing facility, which holds ISO, PED (TÜV), AD 2000, IBR and ASME approvals. We work to ASME B16.9 or EN 10253, in the grades that mining, refining, pulp and paper and power plants in the region actually use, from carbon steel to duplex, 904L and nickel alloys.
| Dimensions | ASME B16.9 / B16.28, EN 10253-2 / -4 |
| Carbon & CrMo | A234 WPB, WP11, WP22, WP91; A420 WPL6 |
| Stainless | A403 WP304L, WP316L, WP317L, 904L |
| Duplex | A815 S31803 / S32205, S32750 super duplex |
| Nickel alloys | Alloy 20, 625, 825, C-276 |
| Size | ½" to 48", Sch 10 to XXS |
| Documents | EN 10204 3.1 std, 3.2 on request |
Sulphuric acid, leach solution, slurry and seawater lines: 316L, 317L, 904L, Alloy 20, duplex and super duplex fittings. See grade selection for sulphuric acid.
Carbon steel, low-temperature WPL6, chrome-moly WP11/WP22/WP5 and pipeline grades WPHY 42–70, with NACE MR0175 options for sour service.
Stainless, duplex and 254 SMO-type fittings for bleach plants, chemical recovery and white liquor service. See pulp and paper.
P11, P22 and P91 fittings for steam lines and HRSGs, including sugar-cane cogeneration boilers.
Duplex and super duplex fittings for seawater intake and reverse-osmosis lines. See desalination.
Mixed container loads of standard ASME B16.9 sizes for stockists. See our distributor programme.
We ship by sea from Nhava Sheva (Mumbai) to Latin American ports including Manzanillo and Veracruz (Mexico), Santos and Rio de Janeiro (Brazil), San Antonio and Valparaíso (Chile), Callao (Peru), Cartagena and Buenaventura (Colombia) and Buenos Aires (Argentina), on FOB, CFR or CIF terms.
Every order includes EN 10204 3.1 certificates with heat-number traceability, a commercial invoice, packing list and certificate of origin. If your country's customs or pre-shipment inspection needs a specific document or certificate format, tell us at the quotation stage.
Correspondence is in English. You can send your bill of quantities in Spanish or Portuguese and we will quote against it line by line.
Yes. We supply ASME B16.9 and EN 10253 buttweld fittings to distributors, EPC contractors, mining companies and plant owners in Mexico, Brazil, Chile, Peru, Colombia, Argentina and neighbouring countries.
It depends on acid concentration, temperature and chlorides. Common choices are 316L and 317L for dilute acid, 904L or Alloy 20 for more aggressive conditions, and duplex or super duplex where chlorides or seawater are present. Send your process conditions and we will suggest suitable grades for your engineer to confirm.
Yes. Send it in the language you use; we will quote line by line and reply in English.
FOB Nhava Sheva, CFR or CIF to your port. Tell us the destination port with your enquiry.
Reply from our Mumbai sales office, usually within one working day. You can attach drawings by email to marketing@arshyafittings.com.
